Complete Casing Design Tools in Wellbore Genie Schematic Software

A Complete Casing Design Feature Set at Your Fingertips

Casing design is at the heart of any wellbore schematic, and Wellbore Genie delivers a comprehensive casing toolset with the flexibility to draw nearly any casing design you can think of — all within the familiar environment of Microsoft Excel.

Complete Casing & Hole Size Inventory

Wellbore Genie includes a full inventory of standard casing sizes and hole sizes, covering everything from large-diameter surface casing to small production strings. Whether you’re diagramming a straightforward two-string well or a complex multi-string architecture, all the sizes you need are built in.

Every Casing Configuration You’ll Encounter

Wellbore Genie handles the full range of casing configurations used in real-world well design:

•      Standard casing strings and open hole sections

•      Liners — including liner hangers

•      Scabbed liners

•      Tapered strings

•      Cut and pulled casing

•      Lead and tail cement interfaces

•      Shoe track cements

•      Casing shoes

If it’s in your well, Wellbore Genie can diagram it.

Visual Customization Controls

Wellbore Genie gives you full control over how every casing element is displayed:

•      Bore size adjustments

•      Line thickness properties

•      Shoe size adjustments

•      Open hole trace visibility

•      Full open hole size adjustments

•      Scaling controls to dial in the diameter and bore display exactly to your preference — adjust casing strings and hole sizes until the diagram looks exactly the way you want it to

This level of control makes Wellbore Genie the ideal casing diagram software for operators, drilling contractors, and service companies who need their schematics to match internal standards or client specifications.
